Silica Brick Is Mainly Used for Coke Oven
| Quantity: | |
|---|---|
Product Description:
Product Brief Introduction:
1. SiO2 :93%-96%.
2. Can according to customers' requirements.
3. Used for various industrial High temperature kilns.
Features：
1. High refractoriness.
2. Have a good fight acid slag erosion ability.
3. High volume stability.
Application:
Silica brick is mainly used for Coke oven, glass kiln, hot-blast stove, tunnel kiln,Acidic furnace non-ferrous metal smelting and some other thermotechnical equipment in good furnace building materials.
Physical and chemical index:
General silica brick: Siliceous refractory products used for various large coke oven, glass kiln stove, hot air stove, etc. | |||
Item | GZ-96 | GZ-95 | GZ-94 |
SiO2 % ≥ | 96 | 95 | 94 |
Fe2O3 % ≤ | 1.0 | 1.2 | 1.4 |
Refractoriness ℃ ≥ | 1710 | 1710 | 1690 |
Apparent porosity % ≤ | 22 | 22 | 24 |
Cold crushing strength Mpa ≥ | 29.4 | 24.5 | 19.6 |
Refractoriness under load, 0.2MPa, °C ≥ | 1660 | 1650 | 1640 |
True density g/cm3 ≤ | 2.34 | 2.35 | 2.35 |
In order to better meet your specific needs and ensure product quality and use effect, please provide the following detailed information before ordering:
I. Product specification requirements
(1) chemical composition requirements
SiO₂ content requirements (e.g. ≥94%, ≥95%, ≥96%)
Fe₂O₃ content requirements (such as ≤1.0%, ≤1.2%, ≤1.4%)
(2) Physical performance requirements
Fire resistance (e.g. ≥1690℃, ≥1710℃)
Load softening temperature (such as ≥1640℃, ≥1650℃, ≥1660℃)
Apparent porosity (such as ≤22% and ≤24%)
Compressive strength at room temperature (such as ≥19.6MPa, ≥24.5MPa, ≥29.4MPa)
True density (e.g. ≤ 2.34g/cm, ≤ 2.35g/cm)
Creep rate (e.g. ≤0.8%, suitable for hot blast stove silicon brick)
Thermal expansion rate (e.g. ≤1.26%, ≤1.28%, ≤1.30%)
Permanent linear change rate (such as 0-+0.2%, suitable for coke oven silicon brick)
(3) Size and appearance requirements
Brick size (please provide detailed drawings or size specifications)
Single weight range (e.g. ≤15kg, 15-25kg, 25-40kg)
Appearance requirements (such as dimensional tolerance, distortion, cracks, corner defects, melting holes, colors, etc.)
II. Product Use and Use Environment
Please specify the specific purpose and use environment of silicon brick, so that we can recommend the most suitable product type for you:
Silicon brick for coke oven (furnace bottom, furnace wall, etc.)
Silicon bricks for glass kiln (BG-96A, BG-96B, BG-95A, BG-95B, etc.)
Silicon bricks for hot blast stoves (vault bricks, checker bricks, etc.)
Other industrial high-temperature kilns (such as tunnel kilns, acid furnaces, nonferrous metal smelting equipment, etc.)
III. Packaging and Transportation Requirements
Packaging method: standard export tray packaging (1000×1000mm), each tray loaded with 1.5-2.0 tons, fixed with PET plastic steel strip and covered with plastic film.
Mode of transportation: 20-foot container loads 24 tons, and 40-foot container loads 28 tons.
Special packaging requirements (if any): Please specify in advance.
IV. Other special requirements
Is it necessary to provide a photo record of the production process of the product?
Do you need an authoritative third-party test report?
Do you need to provide after-sales service such as construction scheme and usage?
V. Ordered quantity and delivery information
Ordered quantity (tons or blocks)
Port of delivery or specific delivery address
Expected delivery time
Please provide the above information as detailed as possible, and we will provide you with the most accurate quotation and the best quality products and services in time according to your specific requirements.
Quality Control:
We have perfect quality control system, Quality inspectors will conduct sampling inspection of all products, Substandard products will be prohibited leaving factory.
Our quality inspection items:
1. Professional quality testing.
① Chemical analysis.②Physical properties.
2. Appearance check.
①Dimension Tolerance. ②Distortion. ③Crack. ④Edge angle defect.⑤Melted hole.⑥Color .
Packaging & shipping:
Packaging:
1.Silica brick will be packed by pallet with PET strap fixed , covering by plastic films.
2. The size of standard export pallet is 1000*1000mm.
Load weight of each pallet:1.5-2.0 Tons.
Shipping:
20 Foot Container can be loaded 24Tons,
40 Foot Container can be loaded 28Tons.
FAQ:
Q1. How to get the exact price?
A: Your detail information about your product is highly appreciated, such as: Specification, Teachnical data ,Size, Drawing, Quantity, Application and Port of discharge, etc. we'll quote you our best price as soon.
Q2. What is the service life of your bricks?
A: The service life of different bricks is unlike.It also depends on your using condition and method.
Q3. How to slove the quality problems?
A: If the goods have quality problems, we will negotiate with you and pay compensation according to the evidence if necessary.
Company Description:
ZIBO ZHUOYUE REFRACTORY CO.,LTD is a specialized manufacturer and exporter of refractories in China. With more than 30 years production experience.
1. Mainly products:Silica brick, Refractory bricks, Refractory castables, Insulating bricks, Insulating castables, Calcined kaolin, Chamotte, Mullite, Ceramic fiber products, etc.
2. Production capacity : Equipped with 2 tunnel kilns , 4 shaft kilns,25 presses machine, 2 castables automatic batching production line,4 Particle and powder production lines,Production capacity of over 100,000 tons per year.
3. Main market : Products are exported to more than 30 countries (Such as South Korea, Japan, German, France, Italy, Indonesia, US, Australia, Malaysia, Philippines, Israel, Jordan, Turkey, Syria, Honduras, South Africa, China Taiwan and so on).
Our Services:
In order to make you more assured of our products, we can provide you with more services:
1. We can provide you with photos of every link of the product.
2. We can provide you with the authoritative test report of the product.
3. We will provide you with a comprehensive after-sales service, such as the quality of the product, construction programs,usage method,etc.
4. If the goods have quality problems, we will negotiate with you and pay compensation according to the evidence.
